TA Instruments Discovery TGA550 is a thermogravimetric analyzer for mass-loss, thermal-stability and composition studies. The dual-range Tru-Mass balance operates with a platinum-rhodium furnace. Hi-Res TGA and modulated TGA extend research-method capabilities.
TEMPERATURERT–1000 °Cstandard furnace
RESOLUTION8 / 60 nglow / high range
SAMPLE MASS1000 mgmaximum
Key benefits
- Dual-range Tru-Mass balance.
- Platinum-rhodium furnace up to 1000 °C.
- Hi-Res TGA mode.
- Modulated TGA (MTGA).
- TRIOS control and data analysis.
- Autosampler and EGA accessories are optional.
Technical specifications
| Model | Discovery TGA550 |
|---|---|
| Standard furnace | Pt/Rh |
| Temperature | RT–1000 °C |
| Linear heating, standard furnace | 0.01–150 °C/min |
| Temperature accuracy | ±1 °C |
| Temperature precision | ±0.1 °C |
| Maximum sample mass | 1000 mg |
| Balance ranges | 100 / 1000 mg |
| Low / high range resolution | 8 / 60 ng |
| Weighing precision | ±0.01% |
| Baseline drift RT–1000 °C without subtraction | <25 µg |
| Cooling 1000→50 °C | <12 min |
| Optional autosampler | 25 positions |
| Software | TRIOS |
Applications and configuration
For research thermal analysis of materials. The standard 150 °C/min limit applies to the platinum-rhodium furnace; the optional EGA furnace has different heating limits. FTIR/MS and external evolved-gas modules are not automatically included. The manufacturer image shows TGA550 with the optional 25-position autosampler. Specify furnace, pans, gases, computer, calibration, utilities and training. TGA5500 infrared-furnace specifications do not apply to this model. Request a quote.
Compare with: Sundy SDTGA6000A.
