Shimadzu GCMS-QP2050 is a single-quadrupole GC-MS system with a DuraEase ion source. This listing selects the Standard version paired with the Brevis GC-2050 gas chromatograph. The Entry version has different sensitivity specifications; a Nexis GC-2030 combination has different dimensions.
MASS RANGEm/z 1.5–1090single quadrupole
SCAN SPEED≤30,000 u/smaximum speed
VERSIONStandardpaired with GC-2050
Key benefits
- The DuraEase design simplifies ion-source replacement during maintenance.
- A pre-rod ahead of the quadrupole limits contamination.
- Fast scanning supports analysis of narrow chromatographic peaks.
- FASST combines Scan and SIM acquisition in one analysis.
- ASSP optimizes rod bias to limit sensitivity loss during fast scanning.
- LabSolutions GCMS combines control, acquisition and data processing.
Technical specifications
| Model and version | GCMS-QP2050 Standard |
|---|---|
| Gas chromatograph | Brevis GC-2050 |
| Analyzer | Single quadrupole |
| Mass range | m/z 1.5–1090 |
| Scan speed | ≤30,000 u/s |
| Ionization | EI |
| Ion source | DuraEase |
| S/N, Standard, helium | ≥5000; 1 pg OFN injection (1 µL) |
| IDL, Standard, helium | ≤5 fg; 100 fg OFN injection (1 µL) |
| Combined Scan/SIM acquisition | FASST |
| System dimensions with GC-2050 | 630 × 600 × 440 mm |
| Software | LabSolutions GCMS |
Applications and configuration
For volatile and semivolatile compounds in prepared samples. For research use only, not for diagnostic procedures. Confirm the Standard version, GC-2050, inlet, column, gases, vacuum system, autosampler, computer and licences. S/N and IDL apply to the stated OFN conditions, not an arbitrary sample matrix. The photograph illustrates the GCMS-QP2050/GC-2050 pair. Request package pricing.
Compare with: Shimadzu GCMS-QP2020 NX.
