Medical pharmaceutical refrigerator Snaige Medical LD14DD-P301Q12
For storage of vaccines, medicines, research samples, reagents and other materials at +2…+16 °C. Gross volume: 130 L; net volume: 100 L. Storage conditions and temperature for each product or material must follow its manufacturer’s instructions.
TEMPERATURE+2…+16 °CAdjustable range
VOLUME130 / 100 LGross / net
DOORSGlassDoor type
ENERGY CONSUMPTION0.646 kWhPer 24 hours
EXTERNAL DIMENSIONS560 × 620 × 870 mmWidth × depth × height
INTERNAL DIMENSIONS465 × 392 × 725 mmWidth × depth × height
Key features
- Control type: Electronic.
- Cooling system: Forced air circulation by fan.
- Visual alarm: Yes.
- Audible alarm: Yes.
- Defrosting: Automatic.
- Temperature recording: Built-in controller memory.
- Controller and alarm backup power duration: At least 24 h.
- Total number of shelves: 4 pcs.
- Maximum load per shelf: 20 kg.
- The backup battery supports the controller, recording and alarms; it does not power cooling.
Technical specifications
| Volume | |
|---|---|
| Gross volume | 130 L |
| Net volume | 100 L |
| Dimensions and weight | |
| External dimensions (W × D × H) | 560 × 620 × 870 mm |
| Internal dimensions (W × D × H) | 465 × 392 × 725 mm |
| Net weight | 38 kg |
| Gross weight without pallet | 41 kg |
| Controls and electronics | |
| Control type | Electronic |
| Visual alarm | Yes |
| Audible alarm | Yes |
| Low temperature protection | Yes |
| Potential-free alarm contact | Provided |
| Additional external sensor port | Provided |
| External sensor port diameter | 12.5 mm |
| Interior lighting type | Top horizontal LED strip |
| Calibration block | Provided |
| Temperature recording | Built-in controller memory |
| Temperature recording interval | 20 min |
| Temperature log retention | 6 months |
| Number of stored alarm records | 5 records |
| Wireless connectivity | Bluetooth |
| Data application | CAREL CONTROLLA |
| Temperature and alarm log export | Via CONTROLLA application |
| Minimum temperature display | Yes |
| Maximum temperature display | Yes |
| Mains power failure alarm | Immediately after power failure |
| Controller and alarm backup power duration | At least 24 h |
| Cooling from backup battery | Not provided |
| External alarm connection | Provided |
| Alarm indication until manual reset | Yes |
| Digital interface | RS485 |
| Local network connection | Via external system and RS485 |
| Low temperature protection threshold | +2 °C |
| Temperature specifications | |
| Minimum storage temperature | +2 °C |
| Maximum storage temperature | +16 °C |
| User setpoint adjustment | Provided, via controller menu |
| Temperature fluctuation | 0.5 °C |
| Temperature gradient | 2.9 °C |
| Cooling | |
| Cooling system | Forced air circulation by fan |
| Defrosting | Automatic |
| Refrigerant | R600a |
| Protection against contact with cold surfaces | Evaporator protective cover |
| Fan stops when door opens | Yes |
| Electrical and energy specifications | |
| Rated voltage | 220–240 V |
| Rated frequency | 50 Hz |
| Energy consumption per 24 hours | 0.646 kWh |
| Annual energy consumption | 236 kWh |
| Heat emission | 135 kJ/h |
| Sound power level relative to 1 pW | 35 dB(A) |
| Power cable length | 240 cm |
| Plug type specified by manufacturer | Euro plug |
| Cabinet, doors and feet | |
| Exterior material | Steel |
| Exterior colour | White |
| Interior material | HIPS polystyrene |
| Door type | Double selective glazing in aluminium profile |
| Self-closing door | Yes |
| Reversible door | Provided |
| Door lock type | Mechanical |
| Door gasket replacement | Provided |
| Number of adjustable front feet | 2 pcs |
| Number of rear feet | 2 pcs |
| Operating conditions | |
| Minimum ambient temperature | +10 °C |
| Maximum ambient temperature | +35 °C |
| Stacking two appliances | Provided by manufacturer; install according to manual |
| Chamber equipment | |
| Total number of shelves | 4 pcs |
| Number of adjustable shelves | 2 pcs |
| Number of bottom shelves | 2 pcs |
| Adjustable shelf width | 420 mm |
| Adjustable shelf depth | 324 mm |
| Bottom shelf 1 width | 465 mm |
| Bottom shelf 1 depth | 263 mm |
| Bottom shelf 2 width | 445 mm |
| Bottom shelf 2 depth | 180 mm |
| Maximum load per shelf | 20 kg |
| Shelf material | Wire grid |
| Shelf coating | White polymer paint |
| Options ordered separately | |
| Perforated metal shelves | Separate order |
| Additional shelf | Separate order |
| Branding | Separate order |
| SNAIGĖ CONNECT GSM notification system | Separate order |
| Product identification | |
| Product name | Medical pharmaceutical refrigerator |
| Model | LD14DD-P301Q12 |
| Brand | Snaige |
| Manufacturer | AB SNAIGĖ |
| Country of manufacture | Lithuania |
| Manufacturer address | Pramonės g. 6, LT-62175 Alytus, Lithuania |
| Packaging and product codes | |
| Factory code without pallet | LD14DD-P301Q123AXXXZ1LT4B |
| EAN without pallet | 4770104114083 |
| Packed dimensions without pallet (W × D × H) | 570 × 640 × 950 mm |
| Factory code with pallet | LD14DD-P301Q123AXXXZ1LT4A |
| EAN with pallet | 4770104114083 |
| Gross weight with pallet | 49.5 kg |
| Packed dimensions on pallet (W × D × H) | 570 × 710 × 1080 mm |
Application and limitations
Do not use for blood, plasma, other infusion fluids, chemically unstable, flammable or alkaline materials. Follow the storage conditions for the specific materials and the manufacturer’s manual.
