Fresenius 4008S classix is a hemodialysis machine with volumetric ultrafiltration control, OCM, DIASAFEplus dialysis-fluid filtration and bibag dry bicarbonate concentrate. It monitors the extracorporeal circuit and prepares dialysis fluid. Equipment, disposables and installation infrastructure must be specified for the dialysis station.
BLOOD FLOW15–600 mL/minpump range
DIALYSATE TEMPERATURE35–39 °Csetting range
ULTRAFILTRATION0–4000 mL/htechnical range
Key benefits
- OCM monitors dialysis-efficiency parameters during treatment.
- DIASAFEplus provides dialysis-fluid filtration.
- The bibag system uses dry bicarbonate concentrate.
- Volumetric balancing supports ultrafiltration control.
- The AdaptedFlow option matches dialysate flow to effective blood flow.
- Monitoring of arterial and venous pressures, air and blood leakage.
Technical specifications
| Model | Fresenius 4008S classix |
|---|---|
| Modalities | HD / ISO-UF |
| Blood pump range | 15–600 mL/min |
| Dialysis-fluid flow | 0 / 300 / 500 / 800 mL/min |
| Dialysis-fluid temperature | 35–39 °C |
| Dialysis-fluid conductivity | 12.8–15.7 mS/cm |
| Ultrafiltration range | 0–4000 mL/h |
| Arterial pressure measurement range | −300…+280 mmHg |
| Venous pressure measurement range | −60…+520 mmHg |
| Water inlet pressure | 1.5–6.0 bar |
| Water inlet temperature | 5–30 °C; hot-rinse conditions per instructions |
| Power supply | 100–240 V AC, 50–60 Hz |
| Dimensions H×W×D | 1370×500×650 mm |
| Approximate weight | 86 kg |
| Filter / bicarbonate | DIASAFEplus / bibag |
| Modules and connectivity | BPM, other monitors and network functions depend on specification |
Applications and configuration
For a dialysis station in a healthcare facility. Requires compatible water treatment, concentrates, drainage, power and scheduled service. The dialyzer, bloodlines, fluids, disposables, chair and water-treatment system are not automatically included. Specify BPM/BTM/BVM monitors, Single-Needle, network interfaces and other options according to configuration availability. The photograph illustrates one equipment configuration. Clinical settings are determined by the medical team using the instructions for use. Request a quotation against a complete specification.
Compare with: Fresenius 5008S CorDiax.
